Mobius 5-Bay FW800, eSATA, USB 3.0 RAID Enclosure
    Mobius 5-Bay FW800, eSATA, USB 3.0 RAID Enclosure
    In stock


    The Mobius™ 5-Bay RAID System is a powerful RAID storage management device with flexible connectivity and easy HDD access. Mobius offers many RAID storage management options including: RAID 0 (Striping), RAID 1 (Mirroring), RAID 10, RAID 3, RAID 5, JBOD (independent disks) and Combine (Span). The LED indicators provide easy verification of operating status and drive health/activity.

    The trayless design provides a simple way of HDD removal and installation – simply pull the handle to insert or withdraw the HDDs. Airflow is maximized due to the high quality, quiet fans that exhaust air away from the internal HDDs, dramatically enhancing internal air flow. The thermally efficient aluminum also maintains optimal HDD operating temperature, prolonging the life of the HDDs.

    Using the Mobius is as easy as using a single bay external enclosure. Simply insert your HDDs, set the RAID mode via the mode switch, connect the cables, and turn on the power for massive storage capacity, redundancy or instant real-time backups.

    • Interface: USB 3.0 / Firewire 800 / eSATA
    • Supports up to five 3.5-inch SATA HDDs (Enterprise drives recommended)
    • Supports SATA hard drives (512 n/e only. Not compatible with 4Kn)
    • Configures RAID modes easily using mode switches
    • Provides JBOD (Default, Non RAID), RAID 0 (Striping), RAID 1 (Mirroring), RAID 10, RAID 3, RAID 5 and Combine
    • Includes two FireWire 800 ports for flexibility via Daisy Chain
    • Monitors system status via LED indicators
    • Features effortless and trayless hard drive insertion
    • Dissipates heat efficiently with aluminum housing & quiet fans
    • Package includes: Mobius 5-Bay RAID, USB 3.0 cable, FireWire 800 cable, eSATA cable, power cord, user guide, key set
    • 2 Year Warranty
    • NOTE: We recommend using only Enterprise or NAS drives. We do NOT recommend the use of consumer-level drives such as WD Green, Blue, Black and Seagate Barracuda. Use of these drives may inhibit performance and limit technical support.


    Ports: USB 3.0, Firewire 800 1394b, eSATA
    RAID Modes: JBOD (default), RAID 0, RAID 1, RAID 3, RAID 5, RAID 10, Combine
    HDD Interface:SATA II (3Gbps). It is compatible with SATA III drives, but will be limited to 3Gbps.
    Speed Tests:
    USB3.0:   JBOD    RAID0    RAID1    RAID5    RAID10    SPAN
    FW800:   JBOD    RAID0    RAID1    RAID5    RAID10    SPAN
    ESATA:   JBOD    RAID0    RAID1    RAID5    RAID10    SPAN
    Fan: Sunon Maglev HA60251V4-000U-999, 13.8 dB(A) x 2
    Power: Input: AC 100~240VAC
    Dimensions: 10.3 x 5.4 x 7.3 inches (L x W x H)
    Certifications:CE, FCC
    Requirements: Compatible with Windows, Mac, Linux
